KIL-1000

MATERIAL:
Fine Cotton fibre fabric with phenolic resin-system

MATERIAL COLOUR: Dark Brown
BENDING STREMGTH: Up to 130N/mm2
TEMPERATURE RESITANCE: Up to 135Deg C
CHEMICAL RESISTANCE: Very Good
WATER ABSORPTION: Low

STANDARD DIMENSIONS:

THICKNESS		WIDTH
mm	(inch)	mm	(inch)
2.3	(0.090)	50 & 75	(2&3)
2.8	(0.110)	50 & 75	(2&3)

KEY FEATURES:
Continuous length to individual specification
Bevel Angle from 15 deg to 90 deg
Rebate or groove

RIVETING Ready for use with rivets, clips and washers. Profiles suit all holder systems

KIL-1500

MATERIAL:
Fine Cotton fibre fabric with phenolic resin-system and graphite impregnation

MATERIAL COLOUR: Black
BENDING STREMGTH: Up to 175N/mm2
TEMPERATURE RESITANCE: Up to 135Deg C
CHEMICAL RESISTANCE: Very Good
WATER ABSORPTION: Low

STANDARD DIMENSIONS:

THICKNESS		WIDTH
mm	(inch)	mm	(inch)
2.3	(0.090)	50 & 75	(2&3)
2.8	(0.110)	50 & 75	(2&3)

KEY FEATURES:
Continuous length to individual specification
Bevel Angle from 15 deg to 90 deg
Rebate or groove

RIVETING Ready for use with rivets, clips and washers. Profiles suit all holder systems

KIL-100

MATERIAL:
Superfine glass fibre fabric with epoxy resin-system

MATERIAL COLOUR: Light Green
BENDING STREMGTH: Up to 400N/mm2
TEMPERATURE RESITANCE: Up to 185 Deg C
CHEMICAL RESISTANCE: Very Good
WATER ABSORPTION: None

STANDARD DIMENSIONS:

THICKNESS		WIDTH
mm	(inch)	mm	(inch)
1.5	(0.090)	50 & 75	(2&3)
1.9	(0.110)	50 & 75	(2&3)

KEY FEATURES:
Continuous length to individual specification
Bevel Angle from 15 deg to 90 deg
Rebate or groove

RIVETING Ready for use with rivets, clips and washers. Profiles suit all holder systems

KIL-200

MATERIAL:
Superfine glass fibre fabric with epoxy resin-system

MATERIAL COLOUR: Yellow Green
BENDING STREMGTH: Up to 400N/mm2
TEMPERATURE RESITANCE: Up to 185 Deg C
CHEMICAL RESISTANCE: Very Good
WATER ABSORPTION: None

STANDARD DIMENSIONS:

THICKNESS		WIDTH
mm	(inch)	mm	(inch)
1.5	(0.090)	50 & 75	(2&3)
1.9	(0.110)	50 & 75	(2&3)

KEY FEATURES:
Continuous length to individual specification
Bevel Angle from 15 deg to 90 deg
Rebate or groove

RIVETING Ready for use with rivets, clips and washers. Profiles suit all holder systems

KIL-300

MATERIAL:
Superfine glass fibre fabric with epoxy resin-system, higher bending strength

MATERIAL COLOUR Red
BENDING STREMGTH: Up to 650N/mm2
TEMPERATURE RESITANCE: Up to 185 Deg C
CHEMICAL RESISTANCE: Very Good
WATER ABSORPTION: None

STANDARD DIMENSIONS:

THICKNESS		WIDTH
mm	(inch)	mm	(inch)
1.5	(0.090)	50 & 75	(2&3)
1.9	(0.110)	50 & 75	(2&3)

KEY FEATURES:
Continuous length to individual specification
Bevel Angle from 15 deg to 90 deg
Rebate or groove

RIVETING Ready for use with rivets, clips and washers. Profiles suit all holder systems



KIL-400

MATERIAL:
Superfine glass fibre fabric with high temperature resistant epoxy resin-system

MATERIAL COLOUR: Green
BENDING STREMGTH: Up to 400N/mm2
TEMPERATURE RESITANCE: Up to 200 Deg C
CHEMICAL RESISTANCE: Very Good
WATER ABSORPTION: None

STANDARD DIMENSIONS:

THICKNESS		WIDTH
mm	(inch)	mm	(inch)
1.5	(0.090)	50 & 75	(2&3)
1.9	(0.110)	50 & 75	(2&3)

KEY FEATURES:
Continuous length to individual specification
Bevel Angle from 15 deg to 90 deg
Rebate or groove

RIVETING Ready for use with rivets, clips and washers. Profiles suit all holder systems



KIL-Abrasive

MATERIAL:
Superfine glass fibre fabric with epoxy resin-system and silicone carbide layers

MATERIAL COLOUR: Dark Brown
BENDING STREMGTH: Up to 130N/mm2
TEMPERATURE RESITANCE: Up to 135Deg C
CHEMICAL RESISTANCE: Very Good
WATER ABSORPTION: Low

STANDARD DIMENSIONS:

THICKNESS		WIDTH
mm	(inch)	mm	(inch)
1.5	(0.060)	50 & 75	(2&3)
1.9	(0.075)	50 & 75	(2&3)
2.3	(0.090)	50 & 75	(2&3)

KEY FEATURES:
Continuous length to individual specification
Bevel Angle from 15 deg to 90 deg
Rebate or groove

RIVETING Ready for use with rivets, clips and washers. Profiles suit all holder systems
