Kingsley coater blades are made from high quality raw materials to the most rigorous specifications which ensure optimal coating.
State-of-the-Art production methods ensure exceptionally fine tolerances for straightness and coating edge finish.

Carbon Steel
Tungsten carbide
Ceramic Coater

MATERIAL:
Carbon Steel C=1.00%, hardness approx. 52-55 HRC

STANDARD DIMENSIONS:
Width: 50-200mm
Thickness: 0.250 / 0.305 / 0.381 / 0.400 / 0.450 / 0.500 / 0.600

KEY FEATURES:
- Continuous length to individual specification
- Hardened, tempered, blue, grey or blue polished, even and straight
- Bevel Angle from 5 deg to 90 deg
- Straightness (max deviation from on-edge 0.4MM in 4 meter length)

MATERIAL:
Primary material – Carbon Steel,
Coating – Tungsten Carbid
Coating Hardness – Apporx 1200 HV
Coating Colour - Silver

STANDARD DIMENSIONS:
Width: 76/84/100 mm
Thickness: 0.305 / 0.381 / 0.457 / 0.508

KEY FEATURES:
- Continuous length to individual specification
- Hardened, tempered, greyish blue and blue straight adjusted
- Individual bevel according to customers’ instruction
- Straightness tolerance max deviation 0.3 mm over 3000 mm.

MATERIAL:
Primary material – Carbon Steel
Coating – Ceramic
Coating Hardness – Apporx 1000 HV
Coating Colour – Light Grey

STANDARD DIMENSIONS:
Width: 76/84/100 mm
Thickness: 0.305 / 0.381 / 0.457 / 0.508

KEY FEATURES:
- Continuous length to individual specification
- Hardened, tempered, greyish blue and blue straight adjusted
- Individual bevel according to customers’ instruction
- Straightness tolerance max deviation 0.3 mm over 3000 mm.
